Flat pan baffles cause issues?
I've got a pan I'm making, its a 2x6 flat pan. I was going to add these baffles, more like braces to help keep things in shape and the bottom of the pan from sagging. Are they necessary or will this big of a pan be fine wide open? I would have made the pan continuous flow but I did not have enough material leftover from making the pan.
I wouldn't put the braces in and use it as it is. Then when possible in the future you can still make it a continuous flow without much problem.Originally Posted by bamboozled
I've got a pan I'm making, its a 2x6 flat pan. I was going to add these baffles, more like braces to help keep things in shape and the bottom of the pan from sagging. Are they necessary or will this big of a pan be fine wide open? I would have made the pan continuous flow but I did not have enough material leftover from making the pan.
Noel Good
1998 to 2009: 15 taps on buckets, scavenged fire pit and pans
2010: New 2x4 SS flat pan w/preheater
2015: New to me Lapierre 18x60 raised flue, new shack, new everything!! 59 taps 23.75 gallons
2016: 85 taps 19 gallons
2017: Purchased 2.5 acres and tubed half with 3/16. 145 taps total 49.25 gallons
2018: 200 taps (162 on 3/16ths 38 on buckets) New NextGen RO 63 gallons
2019: 210 taps 73.5 gallons
2023: 210 taps 89.75 gallons
www.wnybass.com
Leave it without the supports, there not needed. Each inch equals about 7.5 gallons or about 60 pounds. No need for support even if you throw in say 6" it will be just fine.
custom made 2x7 intensofire
With SL pans
250 deer run
300 3/16 (new 2016)
500 sacks around the neighborhood
Alright, I'll leave it alone. I think all I'll do is add a couple straps across the top to keep it from bowing out any.
Looking at the picture, you have enough metal to do a 3 section, continuous flow. Just don't have the lower legs on. dividers might not be as high as sides, but should work!
2018; 3 taps
20"x24"syrup pan on blocks
Turkey frier to finish.
Western NH
Yeah, Bill, I thought the same thing. Turn those upside down, cut a small corner out of each one and make dividers out of them...
Last edited by lpakiz; 02-15-2014 at 06:57 PM. Reason: Spelling and grammar mistakes
I thought continuous flow dividers went from front to back, lengthwise in the pan?
Not on a crossflow pan.
Dividers can go either way... Mine are side to side.. Add raw sap in back and draw off in front..
