I saw how nice a job Brian did on his 2x6 arch so i thought i would look at his design and make my own.
here is the start.
[IMG]http://i1170.photobucket.com/albums/...x1/photo-2.jpg[/IMG]
[IMG]http://i1170.photobucket.com/albums/...x1/photo-3.jpg[/IMG]
http://i1170.photobucket.com/albums/...x1/photo-4.jpg
Test fitting my pans.
[IMG]http://i1170.photobucket.com/albums/...x1/photo-5.jpg[/IMG]
looks good, better work fast if you want to fire it up this season!!!!
We need to assist in filling out the survey. The research done by UVM Proctor Research directly benefits what we love to do.
Thanks to those who have completed the survey so far....but we need a LOT more participation. Please complete the survey at
http://kwiksurveys.com/online-survey...IONKG_c3f8cb68
Don't make me come out there and get you.
Dr. Tim Perkins
UVM Proctor Maple Research Ctr
http://www.uvm.edu/~pmrc
looks good!
Got the door made. The tin on and the fire brick in!
[IMG]http://i1170.photobucket.com/albums/...x1/photo-8.jpg[/IMG]
[IMG]http://i1170.photobucket.com/albums/...1327619048.jpg[/IMG]
[IMG]http://i1170.photobucket.com/albums/...x1/photo-7.jpg[/IMG]
[IMG]http://i1170.photobucket.com/albums/...1327619189.jpg[/IMG]
Almost ready to boil now. In the process of cutting a cupola in the sugar shack now. I will post some pictures of that soon.
[IMG]http://i1170.photobucket.com/albums/...1327619253.jpg[/IMG]
[IMG]http://i1170.photobucket.com/albums/...1/photo-10.jpg[/IMG]
[IMG]http://i1170.photobucket.com/albums/...1/photo-11.jpg[/IMG]
Nice work! Did you or are you going to insulate the door?
No we decided not to because the arch itself is so insulated that we are worried we will not have enough heat to heat the sugar shack.Quote:
Originally Posted by Peepers
We figured we might get some heat off of the door to help warm the 12' x 20' shack.
looks like that door should handle the heat but its gonna be glowing! are you guys doing air over/under the fire too? I've pushed my arch build to next year (I think) but like what everyone on here is doing. good stuff! let us know how it works and what you learn. hope the sap runs good this year!!!
I just picked up a small but powerful squirrel cage fan. We are thinking about fabricating some sort of manifold underneath the grates.Quote:
Originally Posted by Peepers
We will have several holes drilled into tubing or a metal box blowing forced air under the fire. The fan will be mounted underneath the arch behind the firebox so it is out of the way.
Once it is up and running, after a few hours the brick will be hot enough to heat the sugar shack.. Not to mention once you get a good forced air draft you will be opening the door to feed it about every 15 minutes minimum.. I use a stanley squirrel cage fan right in the top center of my fire.. and it will flat out eat the wood.
wow that thing looks heavy, i would have bricked in the shack, but thats just me. hope you got ten men and a boy handy:lol: j/k
looks great
Nice looking rig.
Got the cupola built.
[IMG]http://i1170.photobucket.com/albums/...1/photo-14.jpg[/IMG]
[IMG]http://i1170.photobucket.com/albums/...1/photo-13.jpg[/IMG]
[IMG]http://i1170.photobucket.com/albums/...1/photo-15.jpg[/IMG]
Building a stand to hold my sap tank.
[IMG]http://i1170.photobucket.com/albums/...1/photo-16.jpg[/IMG]
Got the girlfriend making some sap sacks ;)
http://i1170.photobucket.com/albums/...1/photo-17.jpg
1st boil, everything went great. We made 3 1/2 gallons.
[IMG]http://i1170.photobucket.com/albums/...1/photo-18.jpg[/IMG]
Looking good guys! Thanks for posting the pictures.
Where did you get the door
